Star (Middleby) 824TCHSA Ultra-Max Gas Griddles

$8,745.00

Features & Specs

Manufacturer

Star (Middleby)

Brand_name

Ultra-Max

Certifications

cULus, UL EPH Classified, Made in USA

Height

18.0in

Width

24.0in

Depth

34.2in

Shipping Weight

300.0lbs

Cooking Surface Depth (front - back)

24" - 29"

Cooking Surface Width (side - side)

19" - 24"

Exterior Finish

all stainless steel exterior

Griddle Plate Finish

chrome plated

Controls

thermostat / solid state controls

Plate Thickness

1"

Specifications

Ultra-Max® Griddle, countertop gas, 24" W x 24" D cooking surface, 1" thick T1 steel hexavalent chrome griddle plate, 150° - 550° F embedded mechanical snap-action thermostat every 12", 4-3/8" tapered wrap-around splash guard, 3-1/2" front grease trough, heavy-duty metal knobs, standing pilot, welded steel frame with stainless steel exterior, 4" stainless steel legs with 1-3/8" adjustment, 60,000 BTU, cULus, UL EPH Classified, Made in USA
Description
Ultra-Max® Griddle, countertop gas, 24" W x 24" D cooking surface, 1" thick T1 steel hexavalent chrome griddle plate, 150° - 550° F embedded mechanical snap-action thermostat every 12", 4-3/8" tapered wrap-around splash guard, 3-1/2" front grease trough, heavy-duty metal knobs, standing pilot, welded steel frame with stainless steel exterior, 4" stainless steel legs with 1-3/8" adjustment, 60,000 BTU, cULus, UL EPH Classified, Made in USA
24-IN UM GRIDDLE, SNAP-ACTION, NAT GAS, CHROME
