Carter-Hoffmann (Middleby) PH3S Dish & Tray Dispensers
Description
3-Silo Convection Plate / Base Heater
Carter-Hoffmann (Middleby) • Model BH3S-208Designed for demanding banquet, healthcare and institutional service lines, the Carter-Hoffmann 3-Silo Convection Heater safely holds up to 225 plates or 180 wax bases at precise serving temperatures. Factory-configured for plates and field-convertible for bases, it delivers the flexibility you need today—and tomorrow.
Why You’ll Love It
- True dual-mode heating – toggle between “PLATE” (≈230 °F) and “BASE” (≈325 °F) at the flip of a switch.
- High-velocity convection moves hot air evenly across all silos for fast, consistent results.
- Self-leveling elevators keep stacks at the ideal dispensing height and adjust without tools.
- Rugged all-stainless construction with fully welded, turned-in seams for maximum sanitation and durability.
- Removable, gasket-free silo lids hang on built-in hooks—no more misplaced covers.
- Easy mobility on 5 in. all-swivel casters (two locking) and a full-width tubular push handle.
- 10 ft cord & NEMA 6-20P plug—just roll in, plug in and go.
- cULus & UL EPH Classified for electrical safety and sanitation.
Technical Specifications
| Capacity | 180 wax bases (60 per silo) 225 plates (75 per silo) |
|---|---|
| Inside Diameter Range | 7 – 10.25 in. (178 – 260 mm) |
| Heat Source | Forced-air convection, thermostatically controlled |
| Electrical | 208 V / 60 Hz / 1-ph, 4,800 W, 23.1 A, 10 ft cord with NEMA 6-20P |
| Overall Dimensions | 46 3/8 W × 23 D × 45 H in. (1178 × 584 × 1143 mm) |
| Casters | 5 in. all-swivel, two with brakes |
| Shipping Weight | 345 lb (156 kg) |
| Certifications | cULus, UL EPH Classified |
One-Touch Operation
A guarded three-position toggle (BASE / OFF / PLATE) and bright pilot light make operation virtually fool-proof—no recalibration needed.
Built to Work as Hard as You Do
- 18-ga. 300-series stainless exterior with wrap-around single-piece panel.
- 12-ga. stainless base frame handles heavy loads and rough transport.
- High-limit safety thermostat and thermally-protected fan motor guard against overheating.
- Cord wrap keeps power cable secure during storage or transit.
Capacity figures are approximate and may vary with plate/base thickness. Always allow units to preheat for optimum performance.
