Carter-Hoffmann (Middleby) EPD4S10 Dish & Tray Dispensers
Description
Carter-Hoffmann EPD4S10 Enclosed Plate Dispenser
4-Silo • 10 in (254 mm) Plates • Ambient / Non-HeatedKeep up to 200 dinner plates protected, organized, and instantly service-ready. The Carter-Hoffmann EPD4S10 combines rugged, all-stainless construction with smooth mobility for fast-paced tray lines, banquets, cafeterias, and healthcare meal delivery.
Key Benefits
- Four independent silos with drop-in, field-adjustable springs—fine-tune tension for any china weight or stack height.
- Completely welded, turned-in seam cabinet—eliminates raw edges for superior sanitation and long-term durability.
- Full-perimeter red vinyl bumper in a 3/16 in extruded aluminum frame shields walls, doors and the cart itself.
- 5 in (127 mm) all-swivel casters with sealed roller bearings and foot brakes—quiet, effortless maneuvering even when fully loaded.
- Heavy-duty 12-gauge stainless base frame absorbs transport shock and heavy loads.
- Self-supporting flanged tube tops with black dish guides keep stacks centered and scuff-free.
- UL EPH sanitation listed for peace of mind in any commercial food-service environment.
- No electrical connection required—simply load, roll, and serve.
At-a-Glance Specs
| Model | EPD4S10 (ambient) |
|---|---|
| Plate size | 10 in / 254 mm diameter |
| Plate capacity * | Approx. 200 plates (50 per silo) |
| Number of silos | 4 |
| Overall dimensions (H × W × D) | 41 7⁄8 in × 37 1⁄8 in × 37 1⁄8 in 1064 mm × 943 mm × 943 mm |
| Caster diameter | 5 in / 127 mm (all swivel, locking) |
| Construction | All stainless steel cabinet, base frame & tube shields |
| Shipping weight | 235 lb / 107 kg |
| Certifications | UL EPH Sanitation, Made in USA |
*Capacities are approximate and depend on plate profile and stack height.
Ideal For
- Tray makeup & patient meal assembly lines
- Hotel banquet and catering operations
- College & corporate dining facilities
- Restaurants needing portable back-up plate storage
Optional Accessories
- Aluminum drop-on silo covers (specify 10 in)
- Four-corner protective bumpers (in lieu of perimeter bumper)
